JCPOWER JC480.4 480 Watt Class AB 4-Channel Amplifier
JCPOWER JC480.4 480 Watt Class AB 4-Channel Amplifier
Regular price
$149.99 USD
Regular price
Sale price
$149.99 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Enhance your car audio experience with the JCPower JC480.4, a powerful and affordable Class AB 4 channel amp designed to deliver clean, dynamic sound to your speakers.
- Type: Class AB 4 Channel Amp, Full-Range, Budget-Friendly
- RMS Power (2 ohm): 120W x 4
- RMS Power (4 ohm): 80W x 4
- Bridged Power (4 ohm): 220W x 2
- Max Power Output: 480w
- Features: High-level inputs, low-level inputs, speaker-level inputs
- Benefits: Ideal for powering a wide range of car speakers, affordable price point, efficient and reliable performance
-
JCPower System Compatibility:
- Pairs perfectly with the JC2400.1D monoblock amplifier for a complete high-powered system.
- Recommended for use with JC-Series and RS-Series speakers.
General Specifications
| Circuit Topology |
Full Range 4 CH, Class AB |
|---|---|
| RMS Power Output at 2Ω |
120w x 4CH |
| RMS Power Output at 4Ω |
80w x 4CH |
| RMS Power Output at 4Ω Bridged |
240w x 2CH |
| Max Power Output |
480w |
| Total Harmonic Distortion |
≤0.1% |
| Frequency Response |
20Hz – 20kHz |
| Signal to Noise Ratio |
>90dB |
| Gain Range |
0.2 ~ 6V |
| Recommended Fuse type |
30A x 2 |
| Dimensions (L x W x H) |
11.57" × 5.79" × 2.03" |
